MC9S08LL16CGTR
NXP USA Inc.
MC9S08LL16CGTR
NXP USA Inc.
IC MCU 8BIT 16KB FLASH 48QFN
Reference Price (USD)
1+
$3.87340
500+
$3.834666
1000+
$3.795932
1500+
$3.757198
2000+
$3.718464
2500+
$3.67973
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
MC9S08LL16CGTR
$3.87
Product details
The MC9S08LL16CGTR from NXP USA Inc. sets new standards in Embedded - Microcontrollers for building automation systems. Its multi-protocol wireless capabilities and ultra-low power architecture make it perfect for smart HVAC controls and IoT-enabled lighting systems.Featuring S08 technology, this microcontroller executes building control algorithms while consuming just 15 A/MHz in active mode.The 8-Bit architecture processes multiple sensor inputs simultaneously, enabling complex occupancy detection algorithms with 99% accuracy.Operating at 20MHz, the device maintains sub-millisecond response times for critical safety systems like smoke detection and emergency lighting control.With I²C, SCI, SPI support, the microcontroller seamlessly bridges between wired BACnet and wireless Zigbee networks in hybrid building automation systems.Integrated LCD, LVD, POR, PWM, WDT include precision temperature sensors and humidity measurement circuits that eliminate external components in climate control applications.31 configurable interfaces support both digital control signals and analog sensor inputs common in building management panels.16KB (16K x 8) accommodates complete KNX and DALI protocol stacks alongside application code for lighting control scenarios.The FLASH implementation enables secure over-the-air updates for field upgrades without physical access to installed devices.2K x 8 of retention memory preserves system state during power outages, ensuring immediate recovery in critical life safety systems.The 1.8V ~ 3.6V range supports direct operation from 4-20mA current loops commonly used in building automation sensors.Precision A/D 8x12b achieve 0.5 C accuracy in temperature measurement for precise climate control in sensitive environments.The Internal maintains timing accuracy during battery operation, enabling 10-year operation from a single coin cell in wireless sensors.Rated for -40°C ~ 85°C (TA), the device operates reliably in unconditioned spaces like attics and mechanical rooms.Surface Mount packaging withstands vibration and mechanical stress encountered in HVAC equipment installations.The 48-VFQFN Exposed Pad provides enhanced ESD protection for reliable operation in electrically noisy building environments.Available in 48-QFN-EP (7x7), the microcontroller is pre-certified for global building automation standards including EN 14908.
Product Attributes
- Product Status: Active
- Core Processor: S08
- Core Size: 8-Bit
- Speed: 20MHz
- Connectivity: I²C, SCI, SPI
- Peripherals: LCD, LVD, POR, PWM, WDT
- Number of I/O: 31
- Program Memory Size: 16KB (16K x 8)
- Program Memory Type: FLASH
- EEPROM Size: -
- RAM Size: 2K x 8
- Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
- Data Converters: A/D 8x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 48-VFQFN Exposed Pad
- Supplier Device Package: 48-QFN-EP (7x7)
